Tenda TEF1109P 8 Port Poe Switch (8 Normal Poe + 1 Normal Uplink) TEF1109P-8-63W

Tenda TEF1109P 8 Port Poe Switch (8 Normal Poe + 1 Normal Uplink) TEF1109P-8-63W

Rs. 1,893.80
Rs. 0.00 Rs. 1,893.80
Sale Sold out

Tenda TEF1109P 8 Port Poe Switch (8 Normal Poe + 1 Normal Uplink) TEF1109P-8-63W

  • Compatible with IEEE 802.3, IEEE 802.3U, IEEE 802.3Z, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3af, and IEEE 802.3at standards



  • 1.8Gbps backbound bandwidth?1.34Mpps packets forwarding speed?supports nonblocking wire speed Switching.



  • Supports uplink port ligthning-proof?ports 18 are poe-capable?output power of a single port is up to 40W.



  • Transfer distance is up to 150M (standard cat.5E or cat.6).



  • One-key VLAN: Solid dib switch to devide port VLAN easily.



Specification Details
Network Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at
LED Indicator 9 * Link/Ack LED indicators, 1 * Power LED indicator
Interfaces 8 * 10/100 Base-TX Ethernet ports (Data/Power), 1 * 10/100 Base-TX Ethernet port (Data)
Transmission Media Recommended: CAT5/5e UTP or better
Fan Quantity N/A
Dimension 177.5mm x 104.0mm x 26.0mm
Level of Protection Lightning protection for ports: 6KV, Lightning protection for power: 4KV, ESD: Air discharge: ±10kV, Contact discharge: ±8kV
Forwarding Mode Store-and-forward
Switch Capacity 1.8 Gbit/s
Packet Forwarding Rate 1.34Mpps
Buffer 1.25Mb
MAC Address Table 4K
Jumbo Frame N/A
PoE Budget Single port: AF: 15.4W, AT: 30W, Whole device: 58W
Power Consumption /
Input Voltage 100－240V AC 50/60Hz, 51V /1.25A DC (Power Adapter)
Mounting Desktop mounting: support, Wall mounting: support, Rack mounting: non-support
Operating Temperature 0℃ ~ 45℃
Storage Temperature -40℃ ~ 70℃
Operating Humidity 10% ~ 90% non-condensing
Storage Humidity 5% ~ 90% non-condensing
Certification FCC, CE, RoHS
Software Standard: the switch functions as a common unmanaged switch and all the ports of the switch can communicate with each other. VLAN: ports 1 to 8 are isolated from each other, but can communicate with ports 9 (uplink port) respectively.
